Description
The Agilent 1260 Infinity Diode Array Detector (DAD) G1315D is a high-performance liquid chromatography (HPLC) detector designed to provide exceptional sensitivity, resolution, and spectral confirmation for routine analytical workflows. Offering simultaneous acquisition of up to 8 separate wavelengths across a broad spectral range, the G1315D delivers robust data tracking and peak purity verification. Its highly efficient temperature-controlled optical system minimizes baseline drift, making it a reliable workhorse for pharmaceutical, environmental, and chemical analysis laboratories requiring precise peak identification.
Features:
-
Multi-Wavelength Simultaneous Detection: Tracks up to 8 individual signal wavelengths concurrently with programmable bandwidths, ensuring you capture all target compounds and matrix variations in a single run.
-
Excellent Baseline Stability: Features a temperature-controlled optical cell compartment that actively counters environmental temperature fluctuations to significantly reduce baseline noise and drift.
-
Integrated Spectral Verification: Enables automated peak purity determination and spectral library matching across the entire ultraviolet and visible light spectrum, eliminating false positives during analysis.
-
Dual-Lamp Illumination: Combines long-life deuterium and tungsten lamps to provide high-intensity light output, ensuring maximum optical sensitivity from deep UV down to the visible spectrum.
-
Robust Electronic Data Logging: Offers integrated RFID tags on both the flow cells and the UV lamps to automatically track serial numbers, total burn hours, and hardware histories for strict data integrity compliance.
Specifications:
-
Detector Type: 1024-element photodiode array
-
Light Source: Deuterium (UV) and Tungsten (Visible) lamps
-
Wavelength Range: 190 to 950 nm
-
Short-Term Noise: < ±0.7 x 10⁻⁵ AU at 254 and 750 nm
-
Baseline Drift: < 0.9 x 10⁻³ AU/hr at 254 nm
-
Linearity: > 2.0 AU (5%) at 265 nm
-
Data Rate: Up to 80 Hz
-
Flow Cell Options: Standard: 13 µL volume, 10 mm path length (Max pressure: 120 bar)
-
Control & Communications: Controller Area Network (CAN), LAN (via module or main frame), RS-232, APG Remote
-
Dimensions (W x D x H): 13.5 x 17.1 x 5.5 in (34.5 x 43.5 x 14.0 cm)
-
Weight: 26.0 lbs (11.5 kg)
-
Power Requirements: 100–240 VAC, 50/60 Hz, Max 150 VA
