Description
Features:
Epoch 2 Microplate Spectrophotometer includes monochromator-based optics that provides filter-free, wide wavelength range for UV-Vis absorbance measurements in various microplate formats. This spectrophotometer is controlled by Gen5 Software that allows intricate data analysis, yet simple programming. This product is cost-effective and requires low maintenance.
Specifications:
General:
- Detection modes: Absorbance
- Read methods: Endpoint, kinetic, spectral scanning, well area scanning
- Microplate types: 6- to 384-well plates
- Other labware supported: Take 3 Micro-Volume Plates
Absorbance:
- Light source: Xenon flash
- Detector: photodiode
- Wavelength selection: monochromator
- Wavelength range: 200 to 999 nm, in 1 nm increments
- Monochromator bandwidth: 5 nm
- Dynamic range: 0 – 4.0 OD
- Resolution: 0.0001 OD
- Pathlength correction: yes
- Monochromator wavelength accuracy: + 2 nm
- Monochromator wavelength repeatability: + 0.2 nm
- OD accuracy: 0 to 2 OD: +1% +0.010 OD , 2 to 2.5 OD: +3% +0.010 O
- OD linearity: 0 to 2 OD: +% +0.010 OD , 2 to 2.5 OD: +3% +0.010 OD
- OD repeatability: 0 to 2 OD: +1% +0.005 OD , 2 to 2.5 OD: +3% +0.005 OD
- Reading speed (kinetic): 96 wells – 15 seconds | 384 wells – 31 seconds
Physical Characteristics:
- Power: 100 – 240 Volts AC. 50/60 Hz.
- Dimensions: 12″ W x 12.5″ D x 7.7″ H
(30.5 cm x 31.8 cm x 19.6 cm) - Weight <15 lbs (6.8 kg)
