Description
Description
- Oil
- Standard mineral oil provided with the pump.
- Could be PFPE prepared on your specific requirement.
- Anti Suck Back Design
- Prevents vacuum system being oil polluted when pumps stop running.
Technical Specification
- Pumping Speed (50 Hz): 26 m³/h (15 CFM)
- Pumping Speed (60 Hz): 32 m³/h (19 CFM)
- Ultimate Pressure without Gas Ballast:
1.5 × 10⁻³ Torr
2.0 × 10⁻³ mbar - Ultimate Pressure with Gas Ballast:
6.0 × 10⁻³ Torr
8.0 × 10⁻³ mbar - Cooling Method: Air
- Inlet / Exhaust: KF25 / KF25
- Noise Level: 58 dB(A)
- Communication: None
- Oil Type: Hydrocarbon
- Recommended Oil: NPO68
- Oil Capacity: 2 L
- Motor Power: 1.1 kW (1.48 HP)
- Power Supply: Three Phase, 200–220 V / 380–415 V @ 50/60 Hz
- Protection Rating: IP44
- Weight: 95 lb (43 kg)
- Dimensions: 22 × 7 × 11 in (567 × 188 × 276 mm
